Steel panel radiators Oasis Pro are heating devices that are manufactured at the domestic enterprise Forte Prom steel GmbH from cold rolled steel. According to their parameters, panel radiators can be suitable for any room – their height can be from 300 to 600 mm, and the length ranges from 400 to 3000 mm. Thanks to a wide range of products, oasis Pro steel radiators can be used in a wide variety of heating projects.

According to the type of connection, Oasis Pro radiators are of two types: PB-with a side connection and PN-with a lower connection.

Oasis Pro SPRS are structurally divided into 7 types: 10, 11, 20, 21, 22, 30 and 33, where the first digit shows the number of steel panels, and the second digit shows the number of crates that create convection.

All models of Oasis Pro steel panel radiators are guaranteed for 10 years.

  • image description They have high heat transfer
  • image description Modern quality control system
  • image description Insured in Rosgosstrakh for 10 000 000 ₽
  • image description 10 year warranty
  • image description High quality, confirmed by the certificate of conformity GOST 31311-2022
  • image description Made from durable steel



  • All Oasis Pro panel heaters have a high-quality heat-resistant protective and decorative coating in white RAL 9016;
  • The entire painting process consists of surface preparation from the German manufacturer Henkel, a primer from the Italian manufacturer Arsonsisi SpA and the use of European-made nanoral paint . This complex guarantees long-lasting protection for the entire operational life of radiators;
  • Oasis Pro radiators have high heat transfer;
  • The operating pressure of the heating device can reach 10 atmospheres ;
  • They have increased strength and resistance to water hammer;
  • Fittings from Berg, Germany are used for Oasis Pro radiators;
  • Universal connection diameter ½ ”;
  • High product quality is ensured by strict control of the entire production cycle;
  • The warranty period for oasis Pro steel panel radiators is 10 years.
  • Suitable for installation in areas with high hygiene requirements.
  • The special design provides easy cleaning from dirt and dust.

Оптовые закупки для профессионалов рынка

  • Индивидуальная система скидок
  • Наличие всего ассортимента на складе
  • Оперативная доставка в любой регион РФ, даже минимальной партии
  • Гарантия и сервис производителя
  • Оптимальное соотношение цены и качества
  • Более 500 сервисных центров обслуживания по всей стране
  • Система онлайн заказов продукции, позволяющая вам оперативно делать заказы в любое удобное время
Type Height, mm Length, mm Depth, mm Center distance, mm Coolant volume, l Heat Transfer, kW Weight, kg
10 500 400 48,5 449 1 0,344 4,95
10 500 500 48,5 449 1,3 0,431 5,94
10 500 600 48,5 449 1,6 0,517 6,93
10 500 700 48,5 449 1,8 0,603 7,94
10 500 800 48,5 449 2,1 0,689 8,93
10 500 900 48,5 449 2,3 0,775 9,92
10 500 1000 48,5 449 2,6 0,861 10,93
10 500 1100 48,5 449 2,9 0,947 11,92
10 500 1200 48,5 449 3,1 1,033 12,92
10 500 1300 48,5 449 3,4 1,119 13,91
10 500 1400 48,5 449 3,6 1,205 14,90
10 500 1500 48,5 449 3,9 1,292 15,91
10 500 1600 48,5 449 4,2 1,378 16,90
10 500 1700 48,5 449 4,4 1,464 17,98
10 500 1800 48,5 449 4,7 1,55 18,97
10 500 1900 48,5 449 4,9 1,636 19,96
10 500 2000 48,5 449 5,2 1,722 20,97
10 500 2100 48,5 449 5,5 1,808 21,96
10 500 2200 48,5 449 5,7 1,894 22,94
10 500 2300 48,5 449 6 1,98 23,95
10 500 2400 48,5 449 6,2 2,066 24,94
10 500 2500 48,5 449 6,5 2,153 25,95
10 500 2600 48,5 449 6,8 2,239 26,94
10 500 2700 48,5 449 7 2,325 27,93
10 500 2800 48,5 449 7,3 2,411 28,94
10 500 2900 48,5 449 7,5 2,497 29,93
10 500 3000 48,5 449 7,8 2,583 30,94
